koyu — writing architecture as text
koyu is a notation for writing architecture as text (.muro) and the toolchain that reads it.
Space is the primary element. A wall is not a thing; it is the boundary relation between two spaces. An opening is a connection cut into that boundary. What gets authored is spatial regions and the boundary relations between them — plans, areas and circulation are not written but derived.
One room is written like this. Four lines, and it is a complete file.
grid X 0 3600
grid Y 0 4000
level L1 0 h:2400 slab:150
space /L1/a room X1..X2 Y1..Y2koyu plan first.muro -o first.svg
Not one wall is drawn. There is a space, but not one boundary.
Add one more space line. Change nothing else.
grid X 0 3600 5400
grid Y 0 4000
level L1 0 h:2400 slab:150
space /L1/a room X1..X2 Y1..Y2
space /L1/b room X2..X3 Y1..Y2
A wall appears. There is no operation anywhere in this notation that draws a wall. A wall is the boundary relation between two spaces, derived from how those spaces are laid out. Where a pair of touching spaces carries no declaration at all, that means "wall" rather than "undefined".
The resolution is schematic-design level. Not modelling downstand beams is not an omission but a chosen height of abstraction — the early design phase, where BIM has always been too heavy, is exactly where this notation lives. A whole building fits in a few hundred lines of text, which puts architecture on the same ground as git and LLMs.
Where to start
| If you are | Go to |
|---|---|
| new to koyu | Your first .muro — one room to a two-storey house, 30–45 minutes |
| wanting to run it first | Installing koyu — from npm, or from source |
| asking why it has this shape | Explanations — space as primary, walls as relations, what green does not mean |
| already knowing what you want to do | How-to — Add a storey · Subdivide a unit · Let an agent write it |
| looking a word up | Every construct in .muro · The koyu command · The diagnostic code index |
| driving it from a program or an agent | Reading a building from a program · TypeScript API · koyu-mcp |
Two different questions
koyu check tells you whether what is written is consistent as data. That is all it tells you. A two-storey house that declares no door at all passes green, sealed shut.
Architectural validity is what koyu validate says, separately; circulation is answered by koyu doors and daylight by koyu light. That line is drawn in Scope — what a green check means. Never argue from green that a building works — the tutorial walks you into that trap on purpose at stage 5.
The name
戸牖 (koyu) means doors and windows — openings. Laozi, chapter 11: cut doors and windows to make a room; it is the emptiness within, the space, that makes the room useful, not the walls. For a notation in which space is primary, walls are relations, and openings are connections cut into boundaries, this is the oldest source there is. The homophone 固有 (koyu, "proper, intrinsic") is intended too — every space is addressed by a human-readable proper name, its hierarchical path.
The file extension is .muro (室, muro — room). The unit a file holds is not a building component but a room.
